W036119

3.4 Mil White Non-Top Coated Flexible Vinyl / R-214 / 6 mil BKS

QUANTITY:
Specifications
  • Warehouse: WI

3.4 Mil White Non-Top Coated Flexible Vinyl : see other catalog options

A smooth flexible vinyl film with high durability and moisture resistant. It also has good chemical resistance. It is a good stock for outdoor and durable label applications. Special inks are recommended. Please contact your ink supplier for specific recommendations.

Caliper 3.4 mils
Yield 5,576 sq. in/lb
Brightness 87.4 %
Tensile Strength, MD / CD 3800 / 3350 psi
Elongation Rate, MD / CD 120 / 242 %
Regulatory Compliances California Proposition 65, CONEG, CPSIA, REACH 1st - 27th, RoHS

R-214 : see other catalog options

R-214 has good initial tack and adhesion to papers. Adhesion to rigid plastics, films, glass, and painted metals is good. Its firmness gives it very good press runnability and very good trimming characteristics. It is not recommended for water immersion.

Type General Purpose Removable
Classification Emulsion Acrylic
pH Alkaline
Minimum Application Temp. 20 °F
Service Temperature Range 0 to +150 °F
Regulatory Compliances CONEG, RoHS 1, 2 & 3, REACH through 01/23/24 (240 components)

6 mil Layflat BKS : see other catalog options

A clay-coated kraft liner. Recommended for roll-to-sheet or roll-to-fanfold applications.

Basis Weight (25 x 38 / 500) 88.5 lbs.
Caliper 6.2 mils
Gloss, 75° 18 %
Tear, MD / CD 90 / 108 g
Tensile, MD / CD 46 / 19 lbs.
Regulatory Compliances ASTM F963 Child Toy Safety, CONEG, RoHS, CPSIA
